RE9016 Crossed Roller Bearings 90 ID X 130 OD X 16mm Width Weight 0.75 Kgs Slewing Ring Bearing

RE9016 Crossed Roller Bearings 90 ID X 130 OD X 16mm Width Weight 0.75 Kgs Slewing Ring Bearing
RE9016 Crossed Roller Bearings 90 ID X 130 OD X 16mm Width Weight 0.75 Kgs Slewing Ring Bearing RE9016 Crossed Roller Bearings 90 ID X 130 OD X 16mm Width Weight 0.75 Kgs Slewing Ring Bearing RE9016 Crossed Roller Bearings 90 ID X 130 OD X 16mm Width Weight 0.75 Kgs Slewing Ring Bearing

Großes Bild :  RE9016 Crossed Roller Bearings 90 ID X 130 OD X 16mm Width Weight 0.75 Kgs Slewing Ring Bearing

Produktdetails:
Herkunftsort: CHINA
Markenname: HDBB
Zertifizierung: ISO9001 CO GB
Modellnummer: RE9016
Zahlung und Versand AGB:
Min Bestellmenge: 1pc
Preis: USD or CNY by Negotiation
Verpackung Informationen: Einzelner Farbkasten/industrielle Verpackung
Lieferzeit: 5-7 Arbeitstage
Zahlungsbedingungen: T/T, Western Union, CNY, L/C am Anblick
Kontakt

RE9016 Crossed Roller Bearings 90 ID X 130 OD X 16mm Width Weight 0.75 Kgs Slewing Ring Bearing

Beschreibung
Typ des Wälzlagers: Kreuzung Modell: RE9016
Lagertyp: Rolle Gewicht (kg): 0,75
Material: Chromstahl GCr15 Härte: HRC 58-62
Arbeitstemperaturbereich: -20℃ | 80℃ ABEC-Bewertung: ABEC5 (Verfügbar in ABEC7/9)
Hervorheben:

90x130x16 cross roller slewing bearing

,

cross roller slewing bearing

,

cross roller slewing bearing ring

High Quality RE9016 Crossed Roller Bearings 90 ID X 130 OD X 16mm Width Weight 0.75 Kgs Slewing Ring Bearing




1. Size Specifications (Unit: mm)

Size Parameter Value Description
Inner Diameter (d) 90 Bore diameter that matches the shaft for installation
Outer Diameter (D) 130 Diameter of the outer ring, used for fitting with the bearing housing
Width (B) 16 Axial thickness of the bearing, affecting space occupation in assemblies
Minimum Chamfer Radius (rₘᵢₙ) 1 Small chamfer at the edge to avoid stress concentration and facilitate installation
Roller Pitch Circle Diameter (dₚ) 112 Center-to-center distance of the rollers, related to load distribution
Greasing Hole Diameter (a) 3 Diameter of the hole for injecting lubricating grease
Greasing Hole Depth (b) 1.6 Depth of the greasing hole to ensure effective grease filling
Max Shoulder Height (dₛ) 98 ~ 100 Maximum allowable height of the shoulder on the inner ring side
Min Shoulder Height (dₕ) 118 ~ 122 Minimum required height of the shoulder on the outer ring side

2. Key Features

Feature Category Specific Details
Structural Advantage - Integrated outer ring and separable inner ring, enabling easy clearance adjustment or preloading

- Equipped with separators to prevent roller skew and reduce inter-roller friction
Performance Strength - High rigidity: Linear contact between rollers and raceways minimizes elastic deformation under load

- Multi-load bearing capacity: Can bear radial load, double-direction thrust load, and overturning moments simultaneously via 90° crossed roller arrangement

- High precision: Available in ultra-precision P2 class, meeting strict rotation accuracy requirements
Usage Convenience - Greasing hole design for easy lubrication, extending service life

- Wide working temperature range (-20℃ ~ 80℃) to adapt to various working environments

- Open type (standard) and double-sided seal (RE9016UU) options for different protection needs

3. Typical Applications

Application Field Specific Usage Scenarios
Industrial Automation - Joints and rotating parts of industrial robots (e.g., robotic arms for assembly lines)

- Rotary tables of machining centers (ensuring high-precision rotation during cutting)
Precision Equipment - Medical equipment (e.g., rotating components of diagnostic machines like CT scanners)

- Measuring instruments (e.g., precision coordinate measuring machines)
High-Tech Manufacturing - IC manufacturing machines (e.g., wafer handling equipment requiring ultra-precision)
Heavy-Duty Machinery - Rotating parts of construction/agricultural machinery (withstanding heavy loads and harsh conditions)

Größe und Tag:

mit einer Breite von mehr als 20 mm,

Slewing crossed roller bearings,

Drehverbindungen mit gekreuzten Rollenlagern
